I explained basic 3 parts of script logic in the last post. It was Scoping, Calculation and writing.
We will find out more advanced features for scoping In this post.
1. Scope using member property
We found how to use *XDIM_MEMBERSET last time.
*XDIM_MEMBERSET is for scoping based on the member ID.
What if user wants to scope members based on a specific property value?
For example, a user wants to filter Account dimension members those are Asset.
To achieve this, we need to use ACCTYPE property which has the type value of account.
AST is the value for ASSET account. (Note: Value is based on the APSHELL of BPC.)
The command is *XDIM_FILTER.
The usage is
*XDIM_FILTER <DIMENSIONNAME> = [DIMENSIONName].Properties("Property name") = "Property value"
So above example can be written as below.
*XDIM_FILTER ACCOUNT = [account].properties(“ACCTYPE”)=”AST”
Let's say Account dimension has 3 members as below.
ID ACCTYPE
Extsales INC
CASH AST
TAXES EXP
NETINCOME INC
Then about *XDIM_FILTER_ACCOUNT will select CASH member only.
Let's assume If you already used multiple *XDIM_MEMBERSET command
and below are selected data from the fact tables.
*XDIM_MEMBERSET TIME = 2011.JAN
*XDIM_MEMBERSET CATEGORY = BUDGET
<Result>
EXTSALES , 2011.JAN, BUDGET, 9000
CASH , 2011.JAN, BUDGET, 3000
TAXES , 2011.JAN, BUDGET, 800
NETINCOME, 2011.JAN, BUDGET, 1500
Now if you add *XDIM_FILTER against ACCOUNT dimension.
*XDIM_MEMBERSET TIME = 2011.JAN
*XDIM_MEMBERSET CATEGORY = BUDGET
*XDIM_FILTER ACCOUNT = [account].properties(“ACCTYPE”)=”AST”
Only one record will be selected from above result because CASH is
the only account member that has 'AST' value of ACCTYPE property.
<Result>
CASH , 2011.JAN, BUDGET, 3000
2. Scope using member value
We just figured out how to scope the source data based on the property.
Then someone might ask this question.
"Can we scope based on the value?
For example, can we select all data that an account value greater than 100?
Of course, we can do it.
The command is *XDIM_GETMEMBERSET. Unlike other command,
it needs *ENDXDIM command to specify data.
Here is the grammar of XDIM_GETMEMBERSET and an example.
*XDIM_GETMEMBERSET {dimension} [={member set}]
[*APP={application}] //optional
[*XDIM_MEMBERSET {dimension} [={member set}] //as many of these as needed
[*QUERY_TYPE= 0 | 1 | 2] //optional
*CRITERIA {expression} //required
*ENDXDIM
*XDIM_GETMEMBERSET P_CC=[P_CC].[H1].[AAPJ].CHILDREN
*APP=PLANNING
*XDIM_MEMBERSET P_DataSrc=INPUT
*CRITERIA [P_ACCT].[H1].[CE0001000]>1000
*ENDXDIM
It will get the data and those are..
a. Children member of AAPJ in the P_CC dimension. AND
b. from the PLANNING application AND
c. INPUT member of P_Datasrc dimension AND
d. CE0001000 member's value of the P_ACCT dimension should be greater than 100000
Let's Assume Fact table has below records.
CE0001000, 2011.JAN, ACTUAL, INPUT, KOREA , 2500
CE0002000, 2011.JAN, ACTUAL, INPUT, CHINA , 5000
CE0001000, 2011.JAN, ACTUAL, ADJ , CHINA , 3000
CE0002000, 2011.JAN, ACTUAL, INPUT, JAPAN , 1999
CE0003000, 2011.JAN, ACTUAL, INPUT, JAPAN , 2222
CE0001000, 2011.FEB, BUDGET, ADJ , KOREA , 345
CE0001000, 2011.FEB, BUDGET, INPUT, TURKEY, 1999
CE0003000, 2011.JAN, ACTUAL, INPUT, TURKEY, 1100
CE0001000, 2011.FEB, BUDGET, INPUT, CHINA , 1050
CE0001000, 2011.FEB, BUDGET, INPUT, JAPAN , 450
Which records will be selected?
The answer is
CE0001000, 2011.JAN, ACTUAL, INPUT, KOREA, 2500
CE0001000, 2011.FEB, BUDGET, INPUT, CHINA, 1050
Below records will not be selected even though P_ACCT is CE0001000
because its value is less than 1000
or Datasrc is not INPUT
or it is not the child member of AAPJ (Asia Pacific)
CE0001000, 2011.JAN, ACTUAL, ADJ , CHINA , 3000 (datasrc is not input)
CE0001000, 2011.FEB, BUDGET, ADJ , KOREA , 345 (datasrc is not input)
CE0001000, 2011.FEB, BUDGET, INPUT, TURKEY, 1999 (Turkey is not child member of AAPJ)
CE0001000, 2011.FEB, BUDGET, INPUT, JAPAN , 450 (Value is less than 1000)
Here are some important Notes for using this command.
Note 1: This command works only for BPC MS.
Note 2: if you don't specify each dimension's scope, it will be performed in the
corresponding members of the pre-selected region which is defined with
DIMMEMBERSET of previous line or Passed by Data Manager.
Note 3: This command will generate MDX statement so it takes more time to execute.
if your dataset has only base members, you can use
*XDIM_GETINPUTSET. (please refer help file)
3. When user wants to add more members on top of current scoped data.
Let's say a user wants to add USASales entity on top of predefined memberset.
In that case user defines as below.
*XDIM_ADDMEMBERSET Entity = USASales
The main reason why we need this is
a. Sometimes XDIMMEMBERSET doesn't work with some specific functions like BAS(parent).
For example, IN BPC NW, *XDIM_MEMBERSET = BAS(US),CANADA will not work.
Therefore, we should use *XDIM_MEMBERSET and *XDIM_ADDMEMBERSET.
*Note: In BPC MS, BAS() will not work with XDIM_MEMBERSET.
b. if user always wants to run a specific memberset whenever logic runs,
should use *XDIM_ADDMEMBERSET
4. Dynamic Scope and saving it to a variable.
Sometimes we need to save our scoped data into a script logic variable.
But... what if your dimension members are updated frequently?
As I know, almost every customer updates their dimension at least once a month.
If customer changes their dimension members, what will happen in your script logic?
You can use *Filter but sometimes it may not work all the time.
Then we can use *SELECT and *MEMBERSET command as a dynamic scope tool.
Like other script engine, Logic script also supports Variable to save some data.
The Variable is defined using % symbol.Here are some examples, %MYTIME% , %CUR% etc.
So how can we save some data into the variable and when it can be used?
Usually, the variable can be filled using *SELECT command and *MEMBERSET command.
Both of them is scope command but *SELECT will be faster because it will create SQL statement.
Here is the grammar of both commands.
*SELECT ({variable}, {What}, {From}, {Where})
*MEMBERSET({variable}, {member set in MDX format})
Let's see how to use *SELECT command.
*SELECT(%REPORTING_CURRENCIES%, “ID”, “CURRENCY”, “[GROUP] = 'REP'”)
This command will get the 'member ID(what)' from the 'currency dimension(From)' that the
GROUP property has the value 'REP' (where).
Actually, it will create a SQL statement as below
SELECT ID from mbrCurrency where [GROUP] = 'REP'
After it executes above SQL command, all result will be saved into
%REPORTING_CURRENCIES% variable.
Here is an example of *MEMBERSET which will make same result but execute MDX statement
instead of SQL.
*MEMBERSET(%REPORTING_CURRENCIES%, “filter{[CURRENCY].members,
[currency].properties(“GROUP”)=”REP””)
The variable can be used anywhere in the logic, like in this example:
*XDIM_MEMBER_SET CURRENCY=%REPORTING_CURRENCIES%
Let's assume Currency dimension has below members.
ID GROUP
USD REP
EUR REP
KRW
JPY
Then above statement will be converted as
*XDIM_MEMBER_SET CURRENCY = USD,EUR
When you define and fill in data using *SELECT and *MEMBERSET,
please remember this as 'MEMBERSET Variable'
Note: MEMBERSET command is only supported by MS version.
We reviewed key command of scoping today.
We will review advanced calculation command and control command like *IF or *FOR - *NEXT in the next post.
If you have questions or want to know something about it, please leave a comment.
Thank you.
